Turck JBBS-49SC-M613/EX
SKU: CS3810243MPN: JBBS-49SC-M613/EXAlternate Part #: 6611439UPC/EAN: 4047101006100
6611439 - ISOL DEV COUPLER, FOUNDATION F
$1,467.36
UnitAvailable on backorder
Product Details
FOUNDATION fieldbus
IP67 junction box, 6-channel
- Junction box for wall mounting with stainless steel ⅞” flange connections
- Short-circuit protection per drop line/spur
- Integrated terminating resistor (activatable)
- Cable shielding: Capacitive or direct connection to housing potential selectable via switch
- Isolated support terminal for optional protective conductor incorporated in cable
- Powder-coated die-cast aluminium housing
- Pressure compensation element protects against condensation
- Connection of the housing potential via M5 x 1 bolt
- Entity and FISCO compliant according to IEC 60079-11
Attributes
| Ambient Temperature | -30…+70 °C |
| Approvals | ATEX |
| Connection Technology Signal | ⅞” |
| Customs Tariff Number | 85369095000.0000 |
| Device Type | Active fieldbus junction box |
| Ecl Ss Code V5 1 4 | 27250201 -/- Network components (fieldbus) |
| Fieldbus Protocol | FOUNDATION fieldbus |
| Protection Class | IP67 |
Specifications
| SKU | CS3810243 |
|---|---|
| MPN | JBBS-49SC-M613/EX |
| Alternate Part # | 6611439 |
| UPC/EAN | 4047101006100 |
