Turck GKDF 40-3M/14.5/NPT
SKU: CS3806500MPN: GKDF 40-3M/14.5/NPTAlternate Part #: U-42223
U-42223 - RECEPT,1 ⅜IN.POWERFAST
$98.33
UnitAvailable on backorder
Product Details
Industrial flange connector
with litz wires
- 1 ⅜″ powerfast female receptacle
- Mounting thread: ½″-14 NPT
Attributes
| Application | Power (>11 Amps) |
| Approvals | CE, RoHS, UL 2237 |
| Connector A | Female, 1 ⅜″-16 UN |
| Current | 35 A |
| Customs Tariff Number | 85366990990.0000 |
| Ecl Ss Code V5 1 4 | 27250314 -/- Connection technology |
| Housing Material Finish | Brass, CuZn, Nickel-plated |
| Mounting Orientation | Front mount |
| Mounting Thread | ½″-14 NPT |
| Number Of Contacts | 4 |
| Protection Class When Coupled | IP67, IP68, IP69K |
| Voltage | 600 V |
Specifications
| SKU | CS3806500 |
|---|---|
| MPN | GKDF 40-3M/14.5/NPT |
| Alternate Part # | U-42223 |
