Turck FCS-M18-LIX
SKU: CS3802284MPN: FCS-M18-LIXAlternate Part #: 6870707UPC/EAN: 4047101175110
6870707 - CAL (IMM), COMP-MON, GEN., GEN
$462.79
UnitAvailable on backorder
Product Details
Flow Monitoring
Immersion Sensor with Integrated Processor
- Flow sensor for gaseous media
- Calorimetric principle
- Adjustment via potentiometer
- Power-on LED
- Nickel-plated brass sensor
- DC 3-wire, 19.2…28.8 VDC
- 4…20 mA analog output
Attributes
| Ambient Temperature | -20…+70 °C |
| Approvals | UL |
| Current Output | 4…20 mA |
| Customs Tariff Number | 90261021000.0000 |
| Design | Immersion |
| Detection Type | Calorimetric |
| Ecl Ss Code V5 1 4 | 27273190 -/- Flow meter (not classified) |
| Electrical Connection | Cable |
| Function | Flow monitoring |
| Housing Material | Metal, CuZn |
| Medium | gases |
| Medium Temperature | -20…+70 °C |
| Operating Voltage | 19.2…28.8 VDC |
| Output Function | Analog output |
| Process Connection | M18 × 1 |
| Protection Class | IP67 |
| Sensor Material | Brass |
Specifications
| SKU | CS3802284 |
|---|---|
| MPN | FCS-M18-LIX |
| Alternate Part # | 6870707 |
| UPC/EAN | 4047101175110 |
