All ProductsTurck

Turck BI2-M08E-AN6X-H1341

SKU: CS3788635MPN: BI2-M08E-AN6X-H1341Alternate Part #: 4602952UPC/EAN: 4047101411591

4602952 - FERRITE, BARREL, DC, CON. M12

Turck BI2-M08E-AN6X-H1341, BI2-M08E-AP6X-H1341
$120.15
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

With Increased Switching Distance

  • Threaded barrel, M8 x 1
  • Nickel-plated brass
  • Large sensing range
  • DC 3-wire, 10…30 VDC
  • NO contact, NPN output
  • M12 x 1 male connector

Attributes

Ambient Temperature -25…+70 °C
Construction Size M8 x 1
Customs Tariff Number 85365019900.0000
Design Threaded barrel
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Connector, M12 × 1
Housing Material Metal, CuZn, Nickel Plated
Mounting Flush
Operating Voltage 10…30 VDC
Output Function NO contact, NPN
Protection Class IP67
Rated Switching Distance 2 mm
Special Feature Sn +
Switching Frequency 2.80 kHz

Specifications

SKUCS3788635
MPNBI2-M08E-AN6X-H1341
Alternate Part #4602952
UPC/EAN4047101411591
