Turck BI2-G12-AP6X-0.2-RS4T

SKU: CS3788575MPN: BI2-G12-AP6X-0.2-RS4TAlternate Part #: 4635481

4635481 - FERRITE, BARREL, DC, PIGTAIL M

Turck BI2-G12-AN6X-0.2-RS4T, BI2-G12-AP6X-0.2-RS4T, BI2-G12-AP6X-0.5-RS4T, BI2-M12-AD4X-0.2-RS4.23T, BI2-M12-AN6X-0.2-RS4T, BI2-M12-VP6X-0.2-RS4.4T, BI3-M12-AD4X-0.2-RS4.23T, BI3-M12-AD4X-0.5-RS4.2T, BI3-M12-AD4X-0.7-RS4.2T, BI3-MT12-AD4X-0.5-RS4.23T/S1589, BI3-MT12H-AD4X-0.3-RS4.2T, BI3U-M12-AP6X-0.2-RS4T, BI4-G12-AP6X-0.2-RS4T, BI4-M12-AP6X-0.2-RS4T, BI4U-M12-AP6X-0.3-RS4T
$135.67
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

  • Threaded barrel, M12 x 1
  • Chrome-plated brass
  • DC 3-wire, 10…30 VDC
  • NO contact, PNP output
  • Pigtail with male end M12 x 1

Attributes

Ambient Temperature -25…+70 °C
Construction Size M12 x 1
Design Threaded barrel
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Cable with connector, M12 × 1
Housing Material Metal, CuZn, Chrome-plated
Mounting Flush
Operating Voltage 10…30 VDC
Output Function NO contact, PNP
Protection Class IP67
Rated Switching Distance 2 mm
Switching Frequency 2.0 kHz

Specifications

SKUCS3788575
MPNBI2-G12-AP6X-0.2-RS4T
Alternate Part #4635481
