Turck BI2-EG08K-RN6X
SKU: CS3788466MPN: BI2-EG08K-RN6XAlternate Part #: 4669406UPC/EAN: 4047101159028
4669406 - FERRITE, BARREL, DC, CABLE
$155.03
UnitAvailable on backorder
Product Details
Inductive Sensor
With Increased Switching Distance
- M8 × 1 threaded tube
- Stainless steel, 1.4305 (AISI 303)
- Large sensing range
- DC 3-wire, 10…30 VDC
- NC contact, NPN output
- Cable connection
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | M8 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable |
| Housing Material | Stainless steel, 1.4305 (AISI 303) |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NC contact, NPN |
| Protection Class | IP67 |
| Rated Switching Distance | 2 mm |
| Special Feature | Sn + |
| Switching Frequency | 3.0 kHz |
Specifications
| SKU | CS3788466 |
|---|---|
| MPN | BI2-EG08K-RN6X |
| Alternate Part # | 4669406 |
| UPC/EAN | 4047101159028 |
