Resideo DP4040A5002

4 pole 24 Vac PowerPro Definite Purpose Contactor

Overview:

These three pole definite purpose electromagnetically operated contactors provide switching for starting of induction motors.

Features:

• Shrouded coils on 3 pole (25A to 60A) models protect the coil from harsh environment factors.
• Moisture proof epoxy is used to encapsulate the 3 pole 75A through 120A coils.
• Multiple mounting holes and slots for convenient, interchangeable mounting with most competitive devices.
• Traditional design meets many needs.
• Full array of replacement coils, contact sets and accessories available.
• Application: PowerPro Definite Purpose Contactor
• Electrical Connections (main): lug connectors
• Contact Connections (coil): ¼ in. quick-connects and #6 screws
• Contact Electrical Ratings (AFL @ 277, 480, 600 Vac): 40 A @ 240/277 Vac, 480 Vac, 600 Vac
• Contact Electrical Ratings (Resistive @ 277, 480, 600 Vac): 50 A @ 240/277 Vac, 480 Vac, 600 Vac
