Dwyer DL710

Name: Dwyer DL710
Brand: Dwyer
SKU: CS3643020
Price: 2215.83 USD
Availability: OutOfStock

SKU: CS3643020MPN: DL710Alternate Part #: 124102-04

DL710 DIFF PR DATA LOGGER 10IN

$2,215.83

Unit

Available on backorder

Quantity

remove

add

Product Details

Differential pressure datalogger, range ±10” w.c. (24.9 mbar).

Attributes

Accuracy	±0.05” w.c. (up to 2” range); ±0.1” w.c. (5” and 10” range).
Agency Approval	CE.
Agency Approvals	CE.
Ambient Operating Temperature Rh	-40 to 158°F (-40 to 70°C), 0 to 95% RH, non-condensing.
Clock Accuracy	±2 sec/day plus one sampling interval.
Commodity Code	R1IC
Compensated Temperature Range	32 to 158°F (0 to 70°C).
Computer Requirement	IBM compatible 386 or above and Windows® 3.1 or later with 2MB RAM and 2MB hard drive disk space, one serial port.
Computer Requirements	IBM compatible 386 or above and Windows® 3.1 or later with 2MB RAM and 2MB hard drive disk space, one serial port.
Connection	Two ⅛” I.D. permanent protective tubing.
Drift	±0.5% FS/yr.
Housing Material	PPE & PS (polyphenylene ether & polystyrene).
Hysteresis And Repeatability	±0.05% FS.
Internal Thermistor Range	-40 to 158°F (-40 to 70°C).
Internal Thermistor Resolution	0.7°F (0.4°C), R25 value equal to 10,000Î© [10kÎ© @ 25°C (77°F)].
Max Pressure Rating	4X rated pressure.
Memory Size	21,500 readings.
No Of Channels	Two; internal thermistor, and a differential pressure sensor.
Nonlinearity	±0.05% FS (BFSL).
Power Consumption	5-10 µA.
Power Requirement	3.6 V TL5134 lithium metal battery, internal, factory replaceable.
Resolution	12 bits( 1 in 4096).
Sampling Method	Continuous (first-in, first-out: not available from 40 ms to 8 sec.), Stop when full (fill-then-stop), or delayed start.
Sampling Methods	Continuous (first-in, first-out: not available from 40 ms to 8 sec.), Stop when full (fill-then-stop), or delayed start.
Sampling Rate	Selectable from 0.04 seconds to 8 hours.
Sampling Rates	Selectable from 0.04 seconds to 8 hours.
Service	Dry air and noncorrosive gases.
Thermal Accuracy	±0.5% FS.
