Square D BDL36100

Circuit breaker, PowerPacT B, 100A, 3 pole, 600Y/347VAC, 14kA, lugs, thermal magnetic, 80%

PowerPact B Circuit Breaker, 100A, 3P, 600Y/347V AC, 14kA at 600Y UL EverLink

• Line Rated Current: 100 A
• Number of Poles: 3P
• Control type: Toggle
• Breaking capacity code: D
• Breaking capacity: 14 kA 600Y/347 V AC 50/60 Hz UL 489
• Rated operational voltage: 525 V AC 50/60 Hz UL 489
• Rated service breaking capacity: 4 kA 500...525 V AC 50/60 Hz IEC 60947-2
• Rated impulse withstand voltage: 8 kV IEC 60947-2
• Rated insulation voltage : 800 V IEC 60947-2
• Trip unit technology: Thermal-magnetic
• Utilisation category: Category A
• Mechanical durability: 20000 cycles IEC 947-1 Annex K ed 5.2
• Electrical durability: 10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
• Connection pitch: 1.06 in (27 mm)
• Mounting mode: Clip-on
• Electrical connection: Everlink lug line, Everlink lug load
