Turck BI5U-EM18H-AP6X2-H1141/S395
SKU: CS3638488MPN: BI5U-EM18H-AP6X2-H1141/S395Alternate Part #: 1635158UPC/EAN: 4047101130348
1635158 - UPROX, BARREL, DC, CON. M12
$173.79
UnitAvailable on backorder
Product Details
Inductive Sensor
- Threaded barrel, M18 x 1
- Stainless steel, 1.4301
- Duroplast front cap, very resistant to thermal and mechanical load
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Extended temperature range
- High switching frequency
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- M12 x 1 male connector
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M18 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Housing Material | Stainless steel, 1.4301 (AISI 304) |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP68 |
| Rated Switching Distance | 5 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 2.50 kHz |
Specifications
| SKU | CS3638488 |
|---|---|
| MPN | BI5U-EM18H-AP6X2-H1141/S395 |
| Alternate Part # | 1635158 |
| UPC/EAN | 4047101130348 |
