Eaton 14101RQD07

Name: Eaton 14101RQD07
Brand: Eaton
SKU: CS3608291
Price: 455.83 USD
Availability: OutOfStock

SKU: CS3608291MPN: 14101RQD07UPC/EAN: 782113846682

Eaton Comet 18mm tubular photoelectric sensor

Eaton 14101R6513, 14101R6517, 14101RQD03, 14101RQD07

$455.83

Unit

Available on backorder

Quantity

remove

add

Product Details

Eaton Comet 18mm tubular photoelectric sensor, Polarized Retroreflective, Right Angle, Output ON, M12, 100 mA PNP, 250 mA NPN at 10-30 Vdc, 4 pin, NPN and PNP open collector, 10-30 Vdc

Attributes

Connection	M12
Contact Configuration	NPN and PNP open collector
Contact Rating	100 mA PNP, 250 mA NPN at 10-30 Vdc
Enclosure Material	Polyurethane foam (RIM)
Environmental Rating	NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K
Input Voltage	10-30 Vdc
Led Indicator	Output ON
Maximum Dc Current	100 mA PNP, 250 mA NPN
Number Of Pins	4.0000
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-40 FAH
Operating Temperature Min Uom	FAH
Protection	Auto reset short circuit
Sensor Type	Polarized retroreflective
