Square D METSECT5MD080

Name: Square D METSECT5MD080
Brand: Square D
SKU: CS3362350
Availability: OutOfStock

SKU: CS3362350MPN: METSECT5MD080

current transformer tropicalised DIN mount 800 5 cables d. 40 - bars 12x50 20x40

Product Details

Current transformer tropicalised DIN mount 800 5 cables d. 40, bars 12x50 20x40

In Rated Current	800 A
In Rated Current 1	800 A
Ith Conventional Free Air Thermal Current	48 kA
Ith Conventional Free Air Thermal Current 1	48 kA
Ui Rated Insulation Voltage	3 kV
Ambient Air Temperature For Operation	-25-60 °C
Ambient Air Temperature For Operation 1	-25-60 °C
Current Transformer Ratio	800/5
Current Transformer Type	tropicalised for busbar and cable
Dynamic Withstand Current	2.5 Ith
Electrical Insulation Class	class B
Mounting Mode	by screws# #clip-on# #insulated locking screw
Mounting Support	busbar# #mounting plate# #DIN rail
Opening Of Bars	50.5 x 12.5# #40.5 x 20.5
Product Certifications	CE
Product Name	CT
Product Or Component Type	current transformer
Range	PowerLogic
Relative Humidity	0-95 %
Sealing	without
Secondary Current	0.20833333333333
Standards	VDE 0414# #IEC 61869-2
