Belimo F680-150SHP+GMB24-3-X1
SKU: CS3356403MPN: F680-150SHP+GMB24-3-X1
Butterfly Valve (BFV), 3”, 2-way, ANSI Class 150, Cv 228 |Valve Actuator, Non fail-safe, AC/DC 24 V, On/Off, Floating point
Product Details
Butterfly Valve (BFV), 3”, 2-way, ANSI Class 150, Cv 228 |Valve Actuator, Non fail-safe, AC/DC 24 V, On/Off, Floating point
Attributes
| Control | On/Off Floating point |
| Valve Size | 3” [80] |
| Cv | 228.0 |
| Cv 60° | 125.0 |
| Cv 90° | 228.0 |
| Flow Pattern | 2-way |
| Fail-Safe | Non-Spring Return |
| Nominal Voltage | AC/DC 24 V |
| Close-Off Pressure ∆Ps | 285 psi |
| Transformer Sizing | 6 VA (class 2 power source) |
| Enclosure | UL Enclosure Type 2 |
| Pressure Independent | NO |
| Power Supply | 24 VAC, ±20%, 50/60 Hz, 24 VDC, ±10% |
| Power Consumption In Operation | 4 W |
| Power Consumption In Rest Position | 2 W |
| Electrical Connection | 18 GA plenum cable, 3 ft [1 m], with ½” conduit connector, degree of protection NEMA 2 / IP54 |
| Overload Protection | electronic throughout 0…95° rotation |
| Input Impedance | 600 Ω |
| Angle Of Rotation | Max. 95°, adjustable with mechanical stop |
| Direction Of Motion Motor | selectable with switch 0/1 |
| Position Indication | Mechanically, 30…65 mm stroke |
| Running Time (Motor) | 150 s, constant, independent of load |
| Ambient Humidity | max. 95% r.H., non-condensing |
| Ambient Temperature | -22…122°F [-30…50°C] |
| Storage Temperature | -40…176°F [-40…80°C] |
| Fluid | chilled or hot water, up to 60% glycol, steam |
| Controllable Flow Range | quarter turn, mechanically limited |
| Pipe Connection | ASME/ANSI class 150 flange |
| Ansi Class | 150 |
| Number Of Bolt Holes | 4.0 |
| Lug Threads | ⅝-11 UNC |
| Maximum Inlet Pressure (Steam) | 50 psi |
| Maximum Velocity | 32 FPS |
| Fluid Temp Range (Water) | -22…400°F [-30…204°C] |
| Degree Of Protection Iec/En | IP54 |
| Degree Of Protection Nema/Ul | NEMA 2 |
| Connection | cable |
| Pipe Connection Type | flange |
| Kvs Range [M³/H] | 41…170 m³/h |
| Kvmax Range [M³/H] | 171…1000 m³/h |
| Flow Characteristic | modified equal percentage, unidirectional |
| Servicing | maintenance-free |
| Valve Body | Carbon steel full lug (ASME B16.34) |
| Stem | 17-4 PH stainless steel |
| Seat | RPTFE |
| Nominal Voltage Dc | 24 V |
| Nominal Voltage Ac | 24 V |
| Noise Level, Motor | 45 dB(A) |
| Body Pressure Rating | ANSI Class 150 |
| Quality Standard | ISO 9001 |
| Bearing | glass backed PTFE |
| Disc | 316 stainless steel |
| Agency Listing | cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730-1:02, CE acc. to 2014/30/EU and 2014/35/EU; Listed to UL 2043 - suitable for use in air plenums per Section 300.22© of the NEC and Section 602.2 of the IMC |
| Cv 60° Range [Gpm] | 48…197 |
| Cv 90° Range [Gpm] | 198…1160 |
| Bolt Half Centered | 6.0 |
| Fail-Safe Function | Non fail-safe |
| Control Type Web | Floating/3-point |
| Fail-Safe | NO |
Specifications
| SKU | CS3356403 |
|---|---|
| MPN | F680-150SHP+GMB24-3-X1 |
