Belimo B6400VB-350+GKX24-MFT-X1

Name: Belimo B6400VB-350+GKX24-MFT-X1
Brand: Belimo
SKU: CS3346687
Price: 6653.83 USD
Availability: OutOfStock

SKU: CS3346687MPN: B6400VB-350+GKX24-MFT-X1

Ball Valve (VB), 4”, 2-way, ANSI Class 150, Cv 350 |Configurable Valve Actuator, Electronic fail-safe, AC/DC 24 V, 2...10 V, MFT/programmable

Belimo B6300VB-207+GKB24-3-X1, B6300VB-207+GKX24-MFT-X1, B6400VB-350+GKB24-3-X1, B6400VB-350+GKX24-MFT-X1

$6,653.83

Unit

Available on backorder

Quantity

remove

add

Product Details

Ball Valve (VB), 4”, 2-way, ANSI Class 150, Cv 350 |Configurable Valve Actuator, Electronic fail-safe, AC/DC 24 V, 2...10 V, MFT/programmable

Attributes

Control	MFT/programmable
Valve Size	4” [100]
Cv	350.0
Flow Pattern	2-way
Fail-Safe	Electronic fail-safe 0…100%
Valve Trim	Stainless steel
Nominal Voltage	AC/DC 24 V
Close-Off Pressure ∆Ps	200 psi
Transformer Sizing	21 VA (class 2 power source)
Enclosure	UL Enclosure Type 2
Pressure Independent	NO
Power Supply	24 VAC, ±20%, 50/60 Hz, 24 VDC, ±10%
Power Consumption In Operation	12 W
Power Consumption In Rest Position	3 W
Electrical Connection	18 GA plenum cable with ½” conduit connector, degree of protection NEMA 2 / IP54, 3 ft [1 m] 10 ft [3 m] and 16ft [5 m]
Overload Protection	electronic throughout 0…95° rotation
Operating Range	2…10 V (default), 4…20 mA w/ ZG-R01 (500 Ω, ¼ W resistor), variable (VDC, on/off, floating point)
Operating Range Y Variable	Start point 0.5…30 V End point 2.5…32 V
Input Impedance	100 kΩ for 2…10 V (0.1 mA), 500 Ω for 4…20 mA, 1500 Ω for PWM, On/Off and Floating point
Position Feedback	2…10 V, Max. 0.5 mA, VDC variable
Angle Of Rotation	Max. 95°, adjustable with mechanical stop
Direction Of Motion Motor	selectable with switch 0/1
Position Indication	Mechanically, 30…65 mm stroke
Running Time (Motor)	default 150 s, variable 95…150 s
Running Time Fail-Safe	<35 s
Ambient Humidity	max. 95% r.H., non-condensing
Ambient Temperature	-22…122°F [-30…50°C]
Storage Temperature	-40…176°F [-40…80°C]
Fluid	chilled or hot water, up to 60% glycol, steam
Controllable Flow Range	75°
Pipe Connection	125/150 lb flanged, ASME/ANSI b16.1/b16.5
Ansi Class	150
Number Of Bolt Holes	8.0
Maximum Inlet Pressure (Steam)	150 psi
Max Differential Pressure (Steam)	100 psi
Rangeability Sv	300:1
Fluid Temp Range (Water)	-22…380°F [-30…193°C]
Degree Of Protection Iec/En	IP54
Degree Of Protection Nema/Ul	NEMA 2
Connection	cable
Cv Range [Gpm]	198…1160
Pipe Connection Type	flange
Kvs Range [M³/H]	171…1000 m³/h
Flow Characteristic	equal percentage
Servicing	repack/rebuild kits available
Valve Body	WCC grade carbon steel
Stem	stainless steel
Seat	PTFE
Stem Seal	PTFE V-ring
Housing Material	UL94-5VA
Nominal Voltage Dc	24 V
Nominal Voltage Ac	24 V
Noise Level, Motor	52 dB(A)
Body Pressure Rating	ANSI Class 150
Quality Standard	ISO 9001
Fluid Temp Range (Steam)	-22…380°F [-30…193°C]
Maximum Differential Pressure (Water)	150 psi
Noise Level, Fail-Safe	61 dB(A)
Ball	stainless steel
Agency Listing	cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730-1:02, CE acc. to 2014/30/EU and 2014/35/EU; Listed to UL 2043 - suitable for use in air plenums per Section 300.22© of the NEC and Section 602.2 of the IMC
Fail-Safe Function	Electronic fail-safe
Control Type Web	MFT/Programmable
Fail-Safe	YES
