Schneider Electric SSM3A325F7

Name: Schneider Electric SSM3A325F7
Brand: Schneider Electric
SKU: CS3181147
Price: 168.64 USD
Availability: OutOfStock

SKU: CS3181147MPN: SSM3A325F7Alternate Part #: SENA-SSM3A325F7

single phase relay, Harmony Solid State Modular Relays, 25A, DIN rail mount, zero voltage switching, input 90 to 140V AC, output 48 to 600V AC

$168.64

Unit

Available on backorder

Quantity

remove

add

Product Details

SSR 3 CH 25A 48-600VAC ZC

In Rated Current	25 A
In Rated Current 1	25 A
Absolute Maximum Voltage	1100 V
Ambient Air Temperature For Operation	-20-80 °C
Ambient Air Temperature For Operation 1	-20-80 °C
Ambient Air Temperature For Storage	-40-100 °C
Device Short Name	SSM3
Load Current	0.1-25 A
Marking	CSA# #UL# #CE# #EAC
Marking 1	CSA# #UL# #CE# #EAC
Mounting Support	symmetrical DIN rail
Network Number Of Phases 1	3 phases
Number Of Channels	3.0000
Output Switching Mode	zero voltage switching
Overvoltage Category	III
Pollution Degree	2
Product Certifications	UL# #EAC# #CSA
Product Or Component Type	solid state relay up to 30 A
Range Of Product	Harmony Solid State Relays
Solid State Output Type	zero voltage switching
Standards	IEC 60950-1# #UL 508# #CSA C22.2 No 14
