Turck BI4U-M12-AN6X
SKU: CS3172494MPN: BI4U-M12-AN6XAlternate Part #: 1634823UPC/EAN: 4047101128864
1634823 - UPROX, BARREL, DC, CABLE
$125.93
UnitAvailable on backorder
Product Details
Inductive Sensor
With Extended Switching Distance
- M12 × 1 threaded barrel
- Chrome-plated brass
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Large switching distance
- Recessed mountable
- DC 3-wire, 10…30 VDC
- NO contact, NPN output
- Cable connection
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M12 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable |
| Housing Material | Metal, CuZn, Chrome-plated |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, NPN |
| Protection Class | IP68 |
| Rated Switching Distance | 4 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 3.0 kHz |
Specifications
| SKU | CS3172494 |
|---|---|
| MPN | BI4U-M12-AN6X |
| Alternate Part # | 1634823 |
| UPC/EAN | 4047101128864 |
