Veris AG01

GWN Series carbon monoxide sensors

The AG01 carbon monoxide (CO) sensing element is designed to work with the Veris GWN Series gas platform unit to provide accurate monitoring of CO levels. Common sources of CO include automobile exhaust from gasoline engines, gasoline powered furnaces, gasoline powered water heaters, and gasoline generators. The sensor is calibrated at the factory, so no field calibration is needed. The AG01 is warranted to meet accuracy specifications for two years after the date of manufacture.

Product Applications

• Living Space
• Parking Garage
• Plant Room

Product Specifications

• Sensor Type: Electrochemical
• Measurement Range: 0-300 ppm
• Accuracy: ±3% of range
• Analog Output Scaling: 0-200 ppm
• Resolution: 1 ppm
• Sensor Warranty: 2 years from manufacture date
• Low Level Setpoint: 25 or 35 ppm (switch selectable)
• High Level Setpoint: 180 ppm (fixed)
• Operating Temperature Range: -20° to 50°C (-4° to 122°F)
• Operating Humidity Range: 0-90% RH noncondensing
