Dwyer 626-14-GH-P1-E1-S1

Name: Dwyer 626-14-GH-P1-E1-S1
Brand: Dwyer
SKU: CS3115549
Price: 210.15 USD
Availability: OutOfStock

SKU: CS3115549MPN: 626-14-GH-P1-E1-S1Alternate Part #: 101926-18

626-14-GH-P1-E1-S1 500 PSIG

Dwyer 626-07-GH-P1-E1-S1, 626-08-GH-P1-E1-S1, 626-09-GH-P1-E1-S1, 626-10-GH-P1-E1-S1, 626-11-GH-P1-E1-S1, 626-12-GH-P1-E1-S1, 626-13-GH-P1-E1-S1, 626-14-GH-P1-E1-S1, 626-17-GH-P1-E1-S1, 628-00-GH-P1-E4-S1, 628-07-GH-P1-E4-S1, 628-11-GH-P1-E4-S1, 628-12-GH-P1-E1-S1, 628-12-GH-P1-E4-S1, 628-13-GH-P1-E1-S1

$210.15

Unit

Available on backorder

Quantity

remove

add

Product Details

D1627 Pressure Transmitter Minimum Pressure 0 psi Maximum Pressure 500 psi Electrical Connections Cable Wire Leads Output 4 to 20mA DC Accuracy +/-0.25 Percent of Full Scale Number of Wires 2 Process Connection Gender Male Process Connection Size ¼ in Process Connection Type NPT Power Required 10 to 30V DC NEMA Rating NEMA 4X IP Rating IP66 Series 626 Wiring Entry Cable Gland Maximum Operating Temperature 200 Degrees F Minimum Operating Temperature 0 Degrees F
