Siemens 599-10354
SKU: CS2999826MPN: 599-10354UPC/EAN: 804766018374
599 Series 3-way, ½”, 2.5 Cv Ball Valve
$121.38
UnitAvailable on backorder
Product Details
This 599 Series 3-way ball valve is used to control hot or chilled water and up to 50% Glycol solution in air handlers, convectors, fan coil units, unit conditioners, radiation and reheat coils. This ½-inch valve is 2.5 Cv, with nickel-plated brass ball and brass stem.
Attributes
| Close Off Pressure | 200 psi |
| End Connection | NPT |
| Flow Characteristic | Modified Equal-percentage |
| Flow Coefficient Cv | 2.5000 |
| Leakage Rate | ANSI Class IV |
| Material Inside Set | Ball: Chrome-plated brass;Ball Seal: Glass filled PTFE with EPDM O-rings;Stem: Brass;Stem Seals: EPDM O-rings |
| Material Valve Body | Brass |
| Medium | Water;Water with anti-freeze |
| Medium Temperature | 35…250 ºF |
| Medium Temperature F Max | 250 ºF |
| Medium Temperature F Min | 35 ºF |
| Mounting Position | any |
| Permissible Operating Pressure | 1379 kPa |
| Port Configuration | 3-Way Mixing/Diverting |
| Trim Material | Chrome-plated Brass |
| Valve Body Style | Rotary-Ball |
| Valve Size | 0.5 in |
| Valve Type | Three-way |
Specifications
| SKU | CS2999826 |
|---|---|
| MPN | 599-10354 |
| UPC/EAN | 804766018374 |
