Square D GV2ME063

Name: Square D GV2ME063
Brand: Square D
SKU: CS1658636
Availability: OutOfStock

SKU: CS1658636MPN: GV2ME063

Motor circuit breaker, TeSys Deca, 3P, 1 to 1.6A, thermal magnetic, spring terminals

Product Details

TeSys GV2 Circuit Breaker

Trip Unit Technology: Thermal Magnetic* Poles Description: 3-Pole* Magnetic Tripping Current: 1.6A* Rated Operational Voltage: 690VAC 50/60 Hz conforming to IEC 60947-2* Connections - Terminals: Spring Terminals* Degree of Protection: IP20

Ambient Air Temperature For Storage	-40-80 °C
Control Type	push-button
Device Application	motor protection
Device Short Name	GV2ME
Magnetic Tripping Current	22.5-22.5 A
Maximum Operating Rate	25 cyc/h
Mechanical Durability	100000 cycles
Network Type	AC
Poles Description	3P
Power Dissipation Per Pole	2.5 W
Product Certifications	CCC# #UL# #CSA# #EAC# #ATEX# #BV# #LROS (Lloyds register of shipping)# #UKCA# #DNV-GL# #RINA
Product Name	TeSys GV2# #TeSys Deca
Product Or Component Type	motor circuit breaker
Range	TeSys Deca
Range Of Product	TeSys GV2
Standards	EN/IEC 60947-2# #EN/IEC 60947-4-1
Trip Unit Technology	thermal-magnetic
