Siemens 599-03149
SKU: CS1047282MPN: 599-03149UPC/EAN: 4034106335397
Flowrite 3-Way Valve 1”(25mm) line size, 10 Cv, SS Trim, F×F, ANSI 250
$427.19
UnitAvailable on backorder
Product Details
The Flowrite 599 Series 3-Way Mixing Valve is designed to work with either pneumatic or electronic actuators. This valve has an iron body, stainless steel trim, F×F connections, 1” line size, 10 Cv flow rate and is ANSI Class 250.
Attributes
| Connecting Thread | NPT, direct-coupled universal bonnet |
| End Connection | FxF |
| Flow Characteristic | Equal-percentage |
| Flow Coefficient Cv | 10.0000 |
| High Temperature | NO |
| Leakage Rate | Class IV (0.01% of Cv) |
| Material Inside Set | Body Trim: Stainless Steel; Stem: Stainless Steel ASTM A582 Type 303; Packing: EPDM O-ring;Seat: Single seat metal-to-metal |
| Material Valve Body | UNS CA 844 bronze |
| Medium | Water;Water with anti-freeze |
| Medium Temperature | 20…250 ºF |
| Medium Temperature F Max | 250 ºF |
| Medium Temperature F Min | 20 ºF |
| Mounting Position | any |
| Permissible Operating Pressure | 345 kPa; 50 psi |
| Port Configuration | 3-Way Mixing |
| Rangeability | |
| Stroke | ¾ in., 20 mm |
| Trim Material | Stainless Steel |
| Valve Body Style | Stroke-Globe |
| Valve Size | 1 in |
| Valve Type | Three-way |
Specifications
| SKU | CS1047282 |
|---|---|
| MPN | 599-03149 |
| UPC/EAN | 4034106335397 |
