Schneider Electric 2252-701

Pneunatic Temperature Transmitters - Duct, Range: 50 to 150 F, Averaging Element, 20 ft. long (6.1 m)

Pneunatic Temperature Transmitters - Duct, Range: 50 to 150 F, Averaging Element, 20 ft. long (6.1 m)

• Action: Direct, proportional.* Adjustments: None required, factory calibrated. (Field accessible zero adjustment.)* Supply air pressure: 20 psig ±0.5 psi (138 kPa ±3.4 kPa), clean, dry air, supplied through 1.0 scfh (0.0063” dia.) restrictor or restrictor-tee.* Maximum air pressure: 30 psig (207 kPa).* Output pressure: 3 to 15 psig (21 to 103 kPa).* Air connection: ⅛ in. FNPT.* Maximum case ambient temperature: 140°F (60°C).* Minimum case operating ambient temperature: 40 °F (4.4 °C).* Construction: Liquid-Filled copper sensing element, cast aluminum base, beryllium copper feedback bellows, zinc-plated steel cover.
