Robertshaw 780-003

Spark Ignition Control Lockout PrePurge

Universal Ignition Control Spark Ignition Electrical Connections Terminals 1.5 A 24 V AC Control Volts 1 ¼ in Combined Load 1.5 at .4 PF Flame Sensor Current .7 mA DC @ 25C / 24V AC Main valve 1 amp at .5 PF Pilot valve 1 amp at .5 PF 24 Gas Type NG/LP 5 ⅛ in Prepurge Time (Sec.) 45 sec 3.5 3 3 21/32 in Lockout Time (Sec.) Three 60 Second Valve Trials Interrupted By A Five Minute Purge Cycle Before 100 Percent Lockout
